Japan TELEC certification application

Wireless products exported to Japan need to meet the requirements of Japan's "Radio Law", and type approval (ie, technical regulatory compliance certification) is required for designated radio equipment. The purchase and use of radio equipment that is not certified by TELEC is risky, and it may be harmful if it involves illegal use.

Introduction to TELEC certification

TELEC certification is also called MIC certification. TELEC (Telecom Engineering Center) is the main registered certification body for conformity certification of radio equipment in Japan, MIC (Ministry of Internal Affairs and Communications) is the government agency that regulates radio frequency equipment in Japan, and MIC is the Ministry of Internal Affairs and Communications of Japan, responsible for compiling regulations and standards. TELEC is only one of the designated issuing agencies for MIC, so it is called TELEC certification or MIC certification.

TELEC certification is mandatory, and the certification body is a registered certification body recognized by MIC in the scope of designated radio equipment.

TELEC certification standard

TELEC certified technical standards refer to the classification and technical standards of designated radio equipment listed in the technical regulatory compliance certification system on it. It is worth noting that if there are differences between these technical standards and the technical requirements of the Radio Regulatory Commission Rules No. 18, the Radio Regulatory Commission Rules No. 18 shall prevail.

TELEC certification process

1. Submit an application

2. Sign the quotation and fill in the certification application form

3. Provide samples and provide technical information, pay the first payment

4. The laboratory starts testing after receiving the samples

5. After the test is OK, issue a report

6. Submit the report to the TELEC organization to apply for the TELEC certificate

7. The customer pays the balance

8. TELEC certificate (also called MIC certificate) will be issued after the case is over

TELEC certification submitted information

(1) Application Form (application form);

(2) Technical Spec. (Technical Specifications) The technical specifications must include transmission frequency, support protocol version, transmission power, antenna gain, modulation method, software and hardware version information, etc.;

(3) User’s manual (user manual);

(4) Schematic (circuit schematic diagram);

(5) Block Diagram (circuit block diagram);

(6) Circuit Description (circuit description);

(7) PCB Layout (PCB routing diagram);

(8) Parts Placement (component location map);

(9) Parts List/BOM (component list);

(10) Antenna Report (antenna test report);

(11) Mechanical Diagram (exploded diagram);

(12) RF Module (Radio Frequency Module);

(13) Fixed frequency mode or launch test mode;

(14) ISO9001 certificate of manufacturer or production plant;

(15) Signature document.

For more information about Japanese TELEC certification, please call ZRLK for detailed inquiries. If you have a product that needs TELEC certification, please contact our company ZRLK. We will provide you with professional and efficient testing and certification services, with favorable prices and courteous services. If you provide us with product pictures and specifications, we will give us the corresponding cycle, quotation and specific plan according to your product. Welcome to inquire!
