Classic Bluetooth products handle Japan TELEC certification test project

What is TELEC certification

TELEC is also called MIC certification in Japan, and TELEC is one of the designated issuing agencies of MIC, so it is collectively called TELEC certification. TELEC is a compulsory certification for wireless products in Japan: the "Radio Law" requires the type approval of designated radio equipment (ie, technical compliance certification). The certification body is a registered certification body recognized by MIC in the scope of designated radio equipment. TELEC (Telecom Engineering Center) is the main registered certification body for conformity certification of radio equipment in Japan.

Bluetooth products handle Japan TELEC certification test project

1. Frequency Tolerance

Limit: ±50ppm

Test conditions: test voltage is normal pressure and high and low voltage, test temperature is normal temperature

2. Occupied Bandwidth (99%)

Limit: <83.5MHz

Test conditions: test voltage is normal pressure and high and low voltage, test temperature is normal temperature

3. Spread-Spectrum Bandwidth (90%)

Limit: ≥ 0.5 MHz

Test conditions: test voltage is normal pressure and high and low voltage, test temperature is normal temperature

4. Spurious Emission

Test conditions: test voltage is normal pressure and high and low voltage, test temperature is normal temperature

5. Interference prevention function

Test conditions: test voltage is normal pressure, test temperature is normal temperature

6. Antenna power

Limit: ≤ 3mW

Test conditions: test voltage is normal pressure and high and low voltage, test temperature is normal temperature

7. Limitaion Of Collateral Emissions Of Receiver

Limit: ≥4nW for below 1G, 20nW for above 1G

8. Dwell time

Limit: <0.4s

Test conditions: test voltage is normal pressure, test temperature is normal temperature

For more information about applying for Japanese TELEC certification for Bluetooth products, please call ZRLK for detailed inquiries, and professional engineers will answer you online. If you provide us with product pictures and specifications, we will give us the corresponding cycle, quotation and specific plan according to your product. Welcome to inquire.
